Milling Machine

MODEL		AKA-16SS/VS	AKA-18SS/VS	AKA-860S/VS	AKA-26SHB
SPECIFICATION
WORK TABLE	MM	254*1270	254*1270	300*1370	300*1370
X TRAVEL (with power feed) / MANUAL	MM	850 / 750	760 / 860	860 / 840	1000 / 1000
Y TRAVEL	MM	426	426	400	420
KNEE TRAVEL	MM	380	470	470	470
TABLE TO SPINDLE NOSE	MM	50-430	90-560	20-490	110-580
QUIL TRAVEL	MM	127	140	140	140
MAIN/HORIZONTAL SPINDLE TAPER		R8	NT40	NT40	NT40
MAIN/HORIZONTAL MOTOR	HP	3	5	5	5
MACHINE SIZE (LXWXH)	MM	2000*2530*2320	2000*2530*2490	2000*2830*2490	2200*3100*2550
MACHINE WEIGHT	KG	1100	1500	1700	2200
